HT5000 Series

Reliable charging, simplified.

The HT5000 series of PD source controllers are highly integrated and support a variety of charging protocols. Along with various protections, these controllers feature a 10-bit A/D converter and smart power derating function, ensuring safe and reliable charging for dual-port applications.

The HT5000 series is designed to operate with general ACDC or DCDC controllers, or an I2C interface ACDC or DCDC controller.

The smart choice for PD charging.

  • Safe and Secure

    Equipped with multiple protection schemes

  • Stable

    Provides stable power output

  • Dual port fast charging

    Supports a wide range of fast charging protocols

  • Versatile

    Wide input voltage range

  • Small and compact

    Less components needed for more board space

  • Reliable

    Prevents inrush current and overvoltage

Specifications

  • HT5350

    USB Type-C and PD Source Controller

    -USB PD3.0 and Type-C 1.3

    Support up to 5 FPDOs & 3 APDOs

    Support QC2.0/QC3.0, BC1.2 DCP protocols

    Constant Voltage & Constant Current Limit Regulation

    Built-in VIN and VBUS pins fast discharge scheme

    Small Current Sensing Resistor (5mΩ) for higher efficiency

    CC1/CC2 Pin Protection up to 28V

    Support cable drop compensation (0, 50m, 100m/200mΩ)

    Support Smart Power Derating function at two ports USB application (USB-C or USB-A)

    Integrated VCONN power and eMarker detection

    Built-in adaptive UVP, adaptive OVP, I_OTP, E_OTP , CC_OVP and VCONN_OCP Fault Detections

    View Full Specs >
